Azimuth range | n x 360º |
---|---|
Elevation range | ±25º |
Minimum velocity (Az & El) | 0.1 °/s |
Maximum velocity (Az) | 50 °/s |
Rezolution (Az & El) | ≤ 0.12 mrad |
Positional accuracy (Az & El) | ≤ 1 mrad |
Weight approx. | 7 kg |
Commmunications | RS 422 / Ethernet TCP/IP |
Operating Voltage | 20÷32 Vdc |
